RUGGED RING DOWN PHONE
Rugged Emergency Ringdown Phone
The Rugged Emergency Ringdown Phone is a rugged ring down phone designed to meet the needs of clients who experience phone vandalism. The telephone is made of high-quality gauge 12 brushed stainless steel and standard 10’ rubber coiled cord which are manufactured to a high standard. The Rugged Emergenct Ringdown Phone offers high resistance to vandalism and ensures that the primary function of communication is preserved. It is also equipped with a dual led light which consumes less energy and serves as signals during calls. The telephone can operate effectively at extremely low temperatures and high relative humidity. It is suitable for any weather condition. It is also easy to install. The Rugged Emergency Ringdown Phone is suitable for use in the police station, ATM, hospitals, railway stations, stadium, parking lot and so on.
Features
Type : Signalling Protocol
- SIP (UDP)
Type : Audio Stream
- Protocols: RTP/RTSP
- Codec: G.711
- Volume control: adjustable with automatic adaptive settings
- Full duplex: Yes (AEC)
Type : Power source
- From external source: Type 12V DC (9 – 36V DC), max. 2A
- PoE: 802.3af (Class 0 – Max. 12.95W)
Type : LAN Interface
- Number of LAN interface: 1
- PoE: 802.3af
- Parameter: 10/100BASE-TX with Auto-MDIX, RJ-45
- Recommended cable size: Cat-5e or better
Type : Audio Interface
- Microphone Input: Normal electret microphone
- Amplifier output:
- Class D amplifier, MONO output socket, THD < 1%
- Water Resistant Speaker
- Max. 5W / 8Ω
- Line out socket: 600Ω
Type : LED control output
- Number of output: 3 (LED1+, LED2+, LED3+ terminals)
- Output current: Typ. 20mA
- Output voltage: Max. 12V (see note 1)
Type : Digital Outputs
- Number of outputs: 2 (OUT1+, OUT2+ terminals)
- Type of output: Powered output socket with short-circuit protection
- Output voltage: 12V (see note 1)
- Active output: 7V – 11V DC / 400mA
Type : Logic Input
- Number of input: 2 (IN1+, IN2+ terminals)
- Input type: Galvanized, isolated inputs (opto-isolators)
- Parameters: Uin < 1.1V (L), Uin > 3V (H), max. Uin = 32V
Type : Relay output
- Number of output: 1 (NC, NO, COM terminals)
- Limit parameter (DC): Max. 30VDC/1A
- Limit parameter (AC): Max. 125VAC/0.3A
Type : Mechanical Properties
- Operating temperature: -40°C – 55°C
- Operating relative humidity: 10% – 95% (not-condensing)
- Storage temperature: -40°C – 70°C
- Dimensions:
- 299x216x89 mm (order no. TEC1200R)
- 138x90x26 mm (order no. TEC1200R-IC)
- Weight:
- order no. TEC1200R max. 8.25 lbs.
- order no. TEC1200R-IC max. 6 oz.
- Protection cover grade:
- IP65 (order no. TEC1200R-GLD)
- IP00 (order no. TEC1200R-IC)
- Mounting: Wall or flush mount. Wall mount needs optional back box
Type : Cord
- Rubber Coiled Cord 10’ (optional 3’ armoured cord)
- P/N: 1200R-BB
