Our Products Details
From Elevator Intercoms, POE over 2 wire, Cellular Gateways, Call Center Solutions, and more!
2WIRE
.avif)
Features
Support the local end to power the remote device, the maximum output is 60W.
Reliably receives calls from elevators and can be received when the call agents are unvailable , ensuring reliable communcation with the elevator passanger.
.avif)
Support 2 megapixels HD video transmission.
Enables the app user to quickly call back elevators when a call has been disconnected, ensuring that communication is never lost.
Support multiple cable transmission.
Displays four video feeds from 32 cameras, which automatically changes every 20 seconds, making it easier to monitor elevator traffic.
Support multicast function.
Keeps track of all incoming calls, missed calls and outgoing calls.
Type : Power
- Input : DC44V~57V/1A
- Output : POE30W/POE60W
Type : Transfer
- Transmission Media : Coaxial cable, twisted pair, telephone line, RVV line
- Transmission distance (2×0.75 square millimeter RVV line) : 500 M
- Maximum throughput : 45Mbps
- Multicast : Support IGMP multicast protocol
Type : Connector
- Power input (DC_IN) : 2.1-5.5mm DC socket
- Power output (DC_OUT) : RJ45 (30W: 1,2,3,6; 60W: 1,2,3,6,4,5,7,8)
- Ethernet (data) : RJ45 (1,2 and 3,6)
- Twisted pair signal input and output (TP) : 5.08mm×2 Screw type industrial terminal
- Ground wire : Shell ground
Type : Indicator Line
- Master : The indicator light of the host, it is on when the switch is turned to M, and it is off when the switch is turned to S (select the switch position before powering on)
- Link : The signal connection light is on when the TP signal is connected, and not on when the TP signal is not connected.
- Power : The power indicator light is always on after power on.
- RJ45 Green : Network communication indicator light flashes when communicating.
- RJ45 Yellow : POE indicator, on when POE open, flashing when overload or undervoltage.
Type : Appearance
- Size : 105×95×24 mm
- Color : Black
- Net Weight : 190g
Type : Environment Requirement
- Working Temperature : -20℃~70℃
- Humidity : 0-95%
- Storage humidity : -40℃~85℃
