High-End Smart Security Center Video Phone
Features
.avif)
16 lines with up to 16 SIP accounts
Reliably receives calls from elevators and can be received when the call agents are unvailable , ensuring reliable communcation with the elevator passanger.
Built-in 2 megapixel camera for video calling with privacy shutter
Enables the app user to quickly call back elevators when a call has been disconnected, ensuring that communication is never lost.
Runs on the Android 7.x operating system
Displays four video feeds from 32 cameras, which automatically changes every 20 seconds, making it easier to monitor elevator traffic.
Built-in Bluetooth for connecting Bluetooth headsets and updating CyberKeys
Keeps track of all incoming calls, missed calls and outgoing calls.
Dual-switched autosensing 10/100/1000Mbps network ports
Gives users the option to reject call when the call comes from an empty elevator.
7-way HD audio conferencing & 3-way 1080p 30fps HD video capability
Contains the list of elevators in the station so that app user can easily locate elevators and coommunicate with them directly.
Built-in PoE/PoE+ for power and network connections
Allows user to initiate calls to elevators.
Dual-mic HD speakerphone with advanced echo cancellation & excellent double-talk performance for any scenario
Offers pre-set messages for app users to easily reply to elevator calls, saving time and improving communication.
64-bit quad-core processor, 2GB RAM,and 16GB Flash
Offers pre-set messages for app users to easily reply to elevator calls, saving time and improving communication.
8’’ (1280x800) capacitive 10-point touch screen IPS LCD
Offers pre-set messages for app users to easily reply to elevator calls, saving time and improving communication.
Peripherals include HDMI-in/out, USB, MicroSD, headset jack, EHS Plantronics headsets
Offers pre-set messages for app users to easily reply to elevator calls, saving time and improving communication.
Integrated CyberKey Authorizer to update IR & Bluetooth CyberKeys
Offers pre-set messages for app users to easily reply to elevator calls, saving time and improving communication.
Virtual Network Connection
to control LCD operation
from a RealVNC Viewer.
Offers pre-set messages for app users to easily reply to elevator calls, saving time and improving communication.
Integrate Genetec’s WebSDK
to retrieve camera
information for correct
video stream on incoming
call.
Offers pre-set messages for app users to easily reply to elevator calls, saving time and improving communication.
Type : Protocols/Standards
- SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR)
- DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP, IPv6, OpenVPN®
Type : Network Interfaces
- Dual switched 10/100/1000 Mbps ports with integrated PoE/PoE+
Type : Graphic Display
- 8" 1280x800 capacitive touch screen (10 points) IPS LCD
Type : Camera
- Tiltable 2 megapixel CMOS camera with privacy shutter, 1080p 30fps
Type : Bluetooth
- Yes, integrated Bluetooth 4.2 + EDR
Type : Wi-Fi
- Yes, dual-band (2.4GHz & 5GHz) with 802.11ac a/b/g/n/ac and WMM
Type : Auxiliary Ports
- RJ9 headset jack (allowing EHS with Plantronics headsets)
- 3.5mm stereo headset with microphone
- USB 2.0 port
- micro SD
- HDMI-out (1.4 up to 1080p60fps)
- HDMI-in (1.4 up to 1080p@60fps)
Type : Feature Keys
- 2 function touch keys VOLUME +/-
- 3 dedicated Android touch keys HOME, MENU, and BACK
Type : Voice Codecs and Capabilities
- Wide-band Opus, wide-band G.722, G.711µ/a, G.729A/B, G.726-32, iLBC
- in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO)
- VAD, CNG, AEC, PLC, AJB, AGC, ANS
Type : Video Codecs and Capabilities
- H.264 BP/MP/HP, video resolution up to 1080p
- frame rate up to 30 fps, bitrate up to 4Mbps
- 3-way video conference (1080p@30fps), BFCP
- people video (up to 1080p@30fps) + content video (up to 1080p@15fps)
- anti-flickering, auto focus and auto exposure, camera block
Type : Telephony Features
- Hold, transfer, forward (unconditional/no-answer/busy)
- call park/pickup, 7-way audio conference (including the host)
- shared-call-appearance (SCA) / bridged-line-appearance (BLA)
- virtual MPK, downloadable contacts (XML, LDAP, up to 2000 items)
- call record (local and server), call log (up to 2000 records)
- call waiting, auto answer, XML customization of screen
- flexible dial plan, hot desking
- personalized music ringtones and music on hold
- server redundancy & fail-over
Type : Sample Applications
- Local apps: Contacts, Call History, File Manager, Programmable Key, Settings, Browser, Email, Voicemail, Calculator, Clock, Recorder, CyberAuthorizer, etc.
- Supports third-party Android apps
- API/SDK available for advanced custom application development
Type : Android
- Runs Android 7.x and LC Video API 2.0
Type : Applications Deployment
- Supports Android 7.x compliant applications to be developed, downloaded and embedded on the device with provisioning control
Type : HD Audio
- Yes, 2 omnidirectional microphones, HD handset and speakerphone with support for wideband audio
Type : Base Stand
- Integrated stand with multiple adjustable angles
Type : QoS
- Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Type : Security
- User and administrator level passwords
- MD5 and MD5-sess based authentication
- 256-bit AES encrypted configuration file
- TLS, SRTP, HTTPS
- 802.1x media access control
- Kensington Security Slot (Kensington Lock) support
Type : Multi-language
- English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, Chinese, Korean and Japanese
Type : Upgrade/Provisioning
- Firmware upgrade via TFTP / HTTP / HTTPS or local HTTP upload
- mass provisioning using TR-069
- AES encrypted XML configuration file
- or LC Device Management System (TDMS)
Type : Power & Green Energy Efficiency
- Universal power adapter included: Input: 100-240VAC 50-60Hz; Output 12VDC 1.5A (18W)
- Integrated PoE* 802.3af Class 3, PoE+ 802.3at, Class 4
- *USB enabled only when power supply or PoE+ is used
Type : Temperature and Humidity
- Operation: 0°C to 40°C, Storage: -10°C to 60°C
- Humidity: 10% to 90% Non-condensing
Type : Package Content
- LC-SC1400 phone, handset with cord, base stand, universal power supply, network cable, screen cleaning cloth, quick installation guide, brochure, GPL license
Type : Elevator Code Compliance
- 2020 BCNYS and the 2019 ASME 17.1
